GaN POWER AMPLIFIERS > 5W

MACOM GaN RF power amplifier solutions are designed with the latest GaN-on-SiC and GaN-on-Si technologies. Our MACOM PURE CARBIDE series of GaN-on-SiC power amplifiers offers high performance and reliability for the most demanding applications. Our expanding GaN portfolio is designed to address the challenging requirements of Aerospace & Defense, Industrial, Scientific and Medical applications and 5G wireless infrastructure. MACOM GaN products deliver output power levels ranging from 2 W to over 7 kW and exhibit best in class RF performance with respect to gain and efficiency. For sensitive Aerospace & Defense applications MACOM can offer a US only supply chain with AS9100D Certification.

95 Items

Clear Filters

Min Frequency (MHz)

Max Frequency (MHz)

Supply Voltage (V)

PSAT Watt (W)

Gain (dB)

Efficiency

Test Freq (GHz)

Package


MAPC-A3006 New	GaN-on-SiC Transistor, 18 W, 28 V, DC - 8 GHz	0	8000	28	18.0	12.5	70	3.70	air cavity ceramic package	15
MAPC-A3009 New	GaN-on-SiC Transistor, 60 W, 28 V, DC - 4 GHz	0	4000	28	60.0	16.0	67	2.50	air cavity ceramic package	69
MAPC-A1529 New	GaN Amplifier 100 V, 1450 W Rev. V2P 3 - 700 MHz	3	700	100	1450.0	18.0	72.6	700.00	AC-780S-2	61
MAPC-A1001	GaN Amplifier 50 V, 50 W	30	1400	50	50.0	15.9	61	900.00	5 x 6 mm DFN	47
MAPC-C22440	Thermally Enhanced GaN Amplifier 400 W, 48 V, 2110 - 2200 MHz	2110	2200	48	400.0	15.5	65
MAPC-A3007 New	GaN-on-SiC Transistor, 30 W, 28 V, DC - 6 GHz	0	6000	28	30.0	15.0	67	3.70	air cavity ceramic package	39
MAPC-A1106	GaN Amplifier 50 V, 85 W	0	3300	50	85.0	16.4	72	2.95	7.0 x 6.5 mm DFN	49
MAPC-A1600	GaN Amplifier 160 V, 150 W - MACOM PURE CARBIDE	960	1400	160	150.0	18.0	60	1.10	AC-400S-2	52
MAPC-A1524	GaN Amplifier 45 V, 400 W	1700	2200	45	400.0	16.0	68	2.10	air cavity ceramic package	55
MAPC-A1521	GaN Amplifier 50 V, 150 W	2700	3600	50	150.0	12.8	55	3.50	air cavity ceramic package	52
MAPC-A2025	GaN Amplifier 32 V, 8 W	3300	4200	32	8.0	16.5	59	4.20	4mm	39
MAPC-A1511	GaN Amplifier 100 V, 3000 W	30	700	100	3000.0	18.0	73	700.00	AC-1230S-4	65
MAPC-A3005 New	GaN-on-SiC Transistor, 10 W, 28 V, DC - 8 GHz	0	8000	28	10.0	14.0	68	2.00	air cavity ceramic package	9
MAPC-A2520	GaN Amplifier 50 V, 30 W AVG	3800	4200	50	30.0	14.2	56	4.00	air cavity ceramic package	45
MAPC-A1516	GaN Amplifier 50 V, 500 W	2400	2500	50	500.0	13.6	71	2.45	air cavity ceramic package	57
MAPC-A2503	GaN Amplifier 50 V, 60 W AVG	3700	4000	50	60.0	-2.0	56	3.85	AC-780S-4	46
MAPC-A2004-B	GaN Amplifier 50 V, 90 W	3300	3800	50	90.0	15.0	58	3.60	7.0 x 6.5 mm DFN	50
MAPC-A1519	GaN Amplifier 50 V, 200 W	2900	3300	50	200.0	16.3	57	3.10	AC-360B-2	54
MAPC-C27600-CP	High Power RF GaN Amplifier, 600 W, 48 V, 2500 - 2700 MHz	2500	2700	48	600.0	15.0	54			49
MAPC-A2519	GaN Amplifier 50 V, 90 W AVG	2300	2400	50	90.0	16.5	60	2.35	AC-780S-4	50
MAPC-A2021	GaN Amplifier 32 V, 8 W 1.8 - 2.7 GHz - MACOM PURE CARBIDE	1800	2700	32	8.0	16.4	67	2.70	4	39
MAPC-A1506	GaN Amplifier 52 V, 450 W 2.0 - 2.4 GHz - MACOM PURE CARBIDE	2000	2400	52	450.0	15.0	68	2.20	AC-780S-4	57
MAPC-A1502	GaN Amplifier 50 V, 1250 W 400 - 460 MHz - MACOM PURE CARBIDE	400	460	50	1250.0	16.7	82.1	430.00	AC-1230B-4 AC-1230S-4	61
MAPC-A1602	GaN Amplifier 130 V, 2500 W 960 - 1215 MHz - MACOM PURE CARBIDE	960	1215	130	2500.0	20.0	65	1.15	AC-780S-2	64
MAPC-A1513	GaN Amplifier 52 V, 450 W	1300	1850	52		15.3	60	1.60	AC-780S-4	57
MAPC-A1522	GaN Amplifier 65 V, 1 kW	2700	3100	65	1000.0	17.0			air cavity ceramic package	60
MAPC-A1508	GaN Amplifier 50 V, 700 W 900 - 930 MHz	900	930	50	700.0	18.8	73.2	0.90	AC-780S-2	58
MAPC-A1507	GaN Amplifier 50 V, 1400 W 900 - 930 MHz	900	930	50	1400.0	18.8	77.5	0.90	AC-1230S-4	61
MAPC-A2517	GaN Amplifier 50 V, 30 W AVG 3.3 - 3.8 GHz	3300	3800	50	30.0	15.8	47.9	3.60	AC-780S-4	52
MAPC-A1504	GaN Amplifier 50 V, 500 W 1.2 - 1.4 GHz	1200	1400	50	500.0	18.0	70	1.30	AC-780B-2	57
MAPC-A1605	MACOM Pure Carbide, GaN Amplifier 150 V, 7000 W, 960 - 1215 MHz	960	1215	150	7000.0	20.0	57	1.06	AC-1230SD-4	68
MAPC-A1604	GaN Amplifier 130 V, 5000 W 960 - 1215 MHz	960	1215	130	4999.0	19.0	61.0	1.16	AC-1230B-4 AC-1230S-4	67
MAPC-A1505	GaN Amplifier 50 V, 700 W 2.7 - 3.1 GHz	2700	3100	50	700.0	13.6	58	2.90	AC-1230B-4 AC-1230S-4	58
MAPC-A2011-B	GaN Amplifier 50 V, 90 W 3.7 - 4.0 GHz	3700	4000	50	90.0	15.3		3.85	7.0 x 6.5 mm DFN	50
MAPC-A2500-B	GaN Amplifier 50 V, 60 W AVG 3.4 - 3.8 GHz	3400	3800	50	450.0	16.0	50	3.60	AC-780S-4	57
MAPC-A2506	GaN Amplifier 50 V, 30 W AVG 3.7 - 4.0 GHz	3700	4000	50	220.0	12.5	52.3	3.85	AC-780S-4	53
MAPC-A2001	GaN Amplifier 50 V, 50 W 3.4 - 4.0 GHz	3400	4000	50	50.0	17.0	62	3.60	7.0 x 6.5 mm DFN	47
MAPC-A1500	GaN Amplifier 65 V, 2600 W, 960 - 1215 MHz - MACOM PURE CARBIDE	960	1215	65	2600.0	18.5	66.2	1.06	AC-1230S-4	64
MAPC-A1501	GaN Amplifier 65 V, 1300 W 960 - 1215 MHz - MACOM PURE CARBIDE	960	1215	65	1300.0	17.2	64.5	1.06	AC-780B-2	61
MAPC-A1000	GaN Amplifier 50 V, 25 W, 30 - 2700 MHz - MACOM PURE CARBIDE	30	2700	50	25.0	13.0	51	2.70	7.0 x 6.5 mm DFN	44
MAPC-A1100	GaN Amplifier 50 V, 65 W, DC - 3.5 GHz - MACOM PURE CARBIDE	0	3500	50	65.0	18.0	71	3.50	AC-360S-2	48
MAPC-A1101-AS000	GaN Amplifier 50 V, 85 W, DC - 3.5 GHz - MACOM PURE CARBIDE	0	3500	50	85.0	15.0	70	3.50	AC-360S-2	49
MAPC-A1102	GaN Amplifier 50 V, 150 W, DC - 3.5 GHz - MACOM PURE CARBIDE	0	3500	50	150.0	13.0	65	3.50	AC-360S-2	52
MAPC-A1103	GaN Amplifier 50 V, 270 W DC - 2.7 GHz - MACOM PURE CARBIDE	0	2700	50	270.0	18.4	68.2	2.60	AC-650S-4	54
MAGB-102527-110A0P	GaN Amplifier 48 V, 110 W 2.5 - 2.7 GHz	2500	2700	48	110.0	17.4		2.60	7 mm 16-lead HQFN Package	50
WGC26420 New	Thermally Enhanced GaN Amplifier 400 W, 48 V, 2620 - 2690 MHz	2620	2690	48	400.0	16.5	65
WGC20630-V1A	Thermally Enhanced GaN Amplifier 630 W, 48 V, 1930 - 2020 MHz		2020			14.8
WGC22630	Thermally Enhanced GaN Amplifier 630 W, 48 V, 2110 - 2200 MHz		2200			16.5
GTRB097152NCV1A	Thermally Enhanced GaN Amplifier 820 W, 48 V, 758 - 960 MHz	758	960	48		18.2	68
WGC27630	Thermally Enhanced GaN Amplifier 600 W, 48 V, 2620 - 2690 MHz	2620	2690	48	600.0	14.6	68
WGC18630	Thermally Enhanced GaN Amplifier 48 V, 610 W	1805	1880	48	610.0	16.7	73
WGC40680V1A	Thermally Enhanced GaN Amplifier 500 W, 48 V, 3700 - 3980 MHz	3700	3980	48	500.0	12.3	58
WGC27550V1A	Thermally Enhanced GaN on SiC Amplifier	2496	2690	48	490.0	13.0
WSDC2640-V1	Thermally Enhanced GaN on SiC Ampl	2496	2690	48	70.0	13.0
WSGPC01-V1	Thermally Enhanced GaN on SiC Ampl	2496	2690	48	6.0	13.0
MAGX-101050-002C0P	GaN Amplifier 50 V, 2 W 1 - 5 GHz	1000	5000	50	2.0	15.4	55.3	3.00	4mm	33
NPTB00025C	GaN Power Transistor, 28 V, 25 W DC - 4 GHz	0	4000	28	25.0	13.0		3.00	AC-200B-2
MAGB-104450-015B0P	GaN Amplifier 50 V, 15 W 4.4 - 5.0 GHz	4400	5000	50	15.0	16.0	51		6 x 3 mm DFN	42
MAGB-104550-005B0P	GaN Amplifier 48 V, 5 W 4.5 - 5.0 GHz	4500	5000	48	5.0	19.0	52.3	4.90	4 mm 6-Lead	37
NPTB00004B	GaN Power Transistor, 28 V, 5 W DC - 6 GHz	0	6000	28	5.0	14.8	>50	2.50	SOIC8	37
MAGB-103440-005B0P	GaN Amplifier 48 V, 5 W 3.4 - 4.0 GHz	3400	4000	48	5.0	17.5	55	3800.00	4x4 mm	37
MAGB-103340-015B0P	GaN Amplifier 48 V, 15 W 3.3 - 4.0 GHz	3300	4000	48	15.0	16.8	53	3.60	4mm	42
MAGB-103338-050S0P	GaN Amplifier 48 V, 50 W 3.3 - 3.8 GHz	3300	3800	48	50.0	16.3	48.7	3.60	7.0 x 6.5 mm DFN	47
MAGX-011086A	GaN Amplifier 28 V, 4 W, DC - 6 GHz	0	6000	28	4.0	9.0	>50	5.80	4x4 mm	36
NPA1006A	GaN Amplifier 28 V, 12.5 W 20 - 1000 MHz	20	1000	28	12.5	14.0	65	0.90		41
NPA1008A	GaN Amplifier 28 V, 5 W, 20 - 2700 MHz	20	2700	28	5.0	12.0	>45	1.90	4x4 mm	37
MAGX-100027-002S0P	GaN Transistor 50 V, 2 W DC - 2.7 GHz	0	2700	50	2.0	18.7	58.5		6 x 3 mm DFN	33
MAGx-101214-500L00	GaN Amplifier 50 V, 500 W 1.2 - 1.4 GHz	1200	1400	50	500.0	16.0	73.5		AC-780B-2	57
MAGB-102327-012B0P	GaN Amplifier 48 V, 10 W 2.3 - 2.7 GHz	2300	2700	48	10.0	34.3	70.2	2.70	4mm	40
MAGB-102327-010B0P	GaN Amplifier 50 V, 10 W, 2.3 - 2.7GHz, n40 & n41	2300	2700	50	8.0	17.2	72.2	2.50	4x4 mm	39
MAGB-103440-010B0P	GaN Amplifier 50 V, 10 W, 3.4 - 4.0GHz, n78, n77 & n48	3400	4000	50	10.0	18.1	53.7	3.80	4x4 mm	40
MAGB-103740-008B0P	GaN Amplifier 48 V, 8 W	3700	4000	50	8.0	17.9	16.2	3.90	4x4 mm	39
MAGe-100809-500G00	GaN Amplifier 50 V, 500 W, 896 - 928 MHz	896	928	50	500.0	18.0		0.93	AC-780S-4	57
MAGX-101011-700E00	GaN Amplifier 50 V, 700 W, 1.0 - 1.1 GHz	1000	1100	50	700.0	19.3	70	1.09	AC-780B-2	58
MAGE-102425-300S00	GaN Amplifier 50 V, 300 W, 2.4 - 2.5GHz	2400	2500	50	300.0	16.7	75	2.45	AC-780S-2	55
MAGX-100027-100C0P	GaN Amplifier 50 V, 100 W, DC - 2.7 GHz	0	2700	50	100.0	15.1	59	2.50	TO-272S-2	50
MAGX-100027-300C0P	GaN Amplifier 50 V, 300 W, DC - 2.7 GHz	0	2700	50	300.0	16.3		2.00	TO-272S-4I	55
MAGX-100027-015S0P	GaN Amplifier 50 V, 15 W, DC - 2.7GHz	0	2700	50	15.0	17.2	60	2.50	6 x 3 mm DFN	42
MAGX-100027-050C0P	GaN Amplifier 50 V, 50 W, DC - 2.7GHz	0	2700	50	50.0	16.8	72	2.50	TO-272S-2	47
MAGB-101836-025B0P	GaN Amplifier 50 V, 25 W, 1.8 - 3.6GHz	1800	3600	50	25.0	16.9	29	3.50	5 x 7 mm QFN	44
NPT2018	GaN Amplifier 50 V, 12 W, DC-3.5 GHz	0	3500	50	12.5	19.0	59	2.50	3 x 6 mm 14-Lead PDFN	41
MAGB-103438-020S0P	GaN Amplifier 50 V, 20 W, 3.4 - 3.8GHz, Dual	3400	3800	50	20.0	17.0	28	3.50	5 x 7 mm QFN	43
MAMG-100227-010C0L	GaN Amplifier 28 V, 10 W, 0.225-2.6 GHz	225	2600	28	10.0	22.0	40	2.60	MD1	40
MAGx-011086	GaN Amplifier 28 V, 4 W, DC - 6 GHz	0	6000	28	4.0	9.0	>50	5.80	4x4 mm	36
NPA1003QA	GaN Amplifier 28 V, 5 W, 0.020 - 1.5 GHz	20	1500	28	5.0	18.0	>50	1.00	4x4 mm	37
NPA1006	GaN Amplifier 28 V, 12 W, 0.020 - 1.0 GHz	20	1000	28	12.5	14.0	>45	0.90	6x5mm 8-lead PDFN	41
NPA1007	GaN Amplifier 28 V, 10W, 0.020 - 2.5 GHz	20	2500	28	10.0	10.0	>50	2.00	6x5mm 8-lead PDFN	40
NPA1008	GaN Amplifier 28 V, 5 W, 0.020 - 2.7 GHz	20	2700	28	5.0	12.0	>45	1.90	4x4 mm	37
NPT1004D	GaN Amplifier 28 V, 45 W, DC - 4 GHz	0	4000	28	45.0	13.0	55	2.50	SOIC8NE	47
NPT25015	GaN Amplifier 28 V, 23 W, DC - 3 GHz	0	3000	28	23.0	14.0		2.50	SOIC8NE	44
NPT25100B	GaN Amplifier 28 V, 125 W, 2.1 - 2.7 GHz	2100	2700	28	125.0	16.5	26	2.50	Flange Ceramic Pkg	51
NPT35015	GaN Amplifier 28 V, 18 W, 3.3 - 3.8 GHz	3300	3800	28	18.0	11.0		3.50	SOIC8NE	43
NPTB00004A	GaN Amplifier 28 V, 5 W, DC - 6 GHz	0	6000	28	5.0	17.0	>50	2.50	SOIC8NE	37
NPTB00025B	GaN Amplifier 28 V, 25 W, DC - 4 GHz	0	4000	28	25.0	13.0	>50	3.00	Flange Ceramic Pkg	44
MAPC-A3008	GaN-on-SiC Amplifier, 45 W, 28 V, DC - 6 GHz
